J Index

Jackstone Calculus-a bladder stone with jagged, irregular margins indicating formation in a trabeculated bladder; from "ball and jacks" game
Juxtaphrenic Peak-tent-like projection of the medial hemidiaphragm seen with upper and sometimes middle lobe atelectasis
J-shaped Sella-sella extends under anterior clinoid process and looks like J on side; seen in normals, hydrocephalus or optic chiasm glioma





Mouse over to enlarge image where available
