Image DDX



Case of the Week 360

What's the most likely diagnosis?

  • 83 year-old with abdominal pain and sepsis

Conventional radiograph of abdomen

  1. Gallstone ileus
  2. Necrotic uterine fibroid
  3. Portal venous gas
  4. Sigmoid volvulus
  5. Free air

Additional Image - Right upper quadrant close-up


Additional Image


Right upper quadrant-close-up




3. Portal Venous Gas



More (Click Discussion Tab)

Portal Venous Gas

General Considerations

  • Initially associated with bowel necrosis and death, portal venous gas is now being imaged in many benign conditions
  • Pathophysiologically, thought to be due to some combination of
    • Bowel distension
    • Damage to mucosa
    • Intra-abdominal sepsis

    More ...
