Pneumocystis Carinii Pneumonia
Pneumocystis Jerovecii


General Considerations

  • Most common cause of interstitial pneumonia in immunocompromised patients
  • Organism
    • Protozoan / fungus Pneumocystis carinii (jiroveci)

Predisposed

  • AIDS
  • Debilitated
  • Premature infants
  • Children with hypogammaglobulinemia
  • Other immunocompromised patients
    • Congenital immunodeficiency syndromes
    • Lymphoproliferative disorders
    • Organ transplant recipients
    • Patients on long-term corticosteroid therapy
    • Patients on chemotherapy for cancer

Associated infections

  • CMV
  • Mycobacterium avium-intracellulare (MAI)
  • Herpes simplex

Clinical Findings

  • Severe dyspnea and cyanosis
  • Subacute insidious onset of malaise and slight cough (frequent in AIDS patients)
  • Respiratory failure
  • WBC slightly elevated (polys)
  • Lymphopenia (50%) indicates poor prognosis

Imaging findings

  • Normal CXR in 10-40%
  • Bilateral diffuse symmetric finely granular / reticular interstitial / airspace infiltrates in 80%
    • Characteristic central location
    • Rapid progression to diffuse airspace disease
      • Resembles non-cardiogenic pulmonary edema
  • Pleural effusion and hilar lymphadenopathy are uncommon
    • Atypical pattern in 5%
  • Isolated lobar disease / focal parenchymal opacities
  • Lung nodules ± cavitation
  • Hilar / mediastinal lymphadenopathy
  • Thin- / thick-walled cysts
  • Cavities with predilection for upper lobes

CT Findings

  • Patchwork pattern (56%)
    • Bilateral, asymmetric patchy mosaic appearance
  • Ground-glass pattern (26%)
    • Bilateral, diffuse air-space disease in symmetric distribution
  • Interstitial pattern (18%)
    • Bilateral, symmetric / asymmetric, reticular markings (thickening of lobular septa)
  • Abnormal air-filled spaces (38%)
    • Pneumatocoeles
      • Thin-walled spaces without lobar predilection resolving within 6 months
    • Subpleural bullae due to emphysema
    • Thin-walled cysts
    • Necrosis of pneumocystis granuloma
    • Pneumothorax (13%)
  • Lymphadenopathy (18%)
  • Pleural effusion (18%)

Pulmonary nodules and cavities

  • Usually due to malignancy
    • Leukemia, lymphoma
    • Kaposi sarcoma
    • Metastasis
    • Or septic emboli
  • Pulmonary cavities usually due to superimposed fungal / mycobacterial infection

Nuclear medicine

  • Bilateral and diffuse Ga-67 uptake without mediastinal involvement prior to roentgenographic changes

Course

  • Usually responds to therapy in 5-7 days
  • Effect of prophylactic use of aerosolized pentamidine
    • Redistribution of infection to upper lobes

Complications

  • Cystic lung disease
    • Central location to cysts
  • Spontaneous pneumothorax, frequently bilateral (6-7%)
  • Disseminated extrapulmonary disease (1%)
  • Punctate / rimlike calcifications within enlarged lymph nodes and abdominal viscera

DDx

  • Non-cardiogenic pulmonary edema
  • TB
  • MAI infection

Diagnosis

  • Sputum collection
  • Bronchoscopy with lavage
  • Transbronchial or transthoracic or open lung Bx

Pneumocystis Pneumonia

Pneumocystis Pneumonia. There is diffuse, mostly reticular, interstitial lung disease greater at the bases. This is a similar picture to that of congestive heart failure under other clinical circumstances.
For these same photos without the arrows, click
here

Pneumocystis Pneumonia

Pneumocystis Pneumonia. There is bilateral, mostly reticular, interstitial lung disease (white circles). This is a similar picture to that of congestive heart failure under other clinical circumstances.
