Cervical Aortic Arch

General Considerations

  • Rare congenital anomaly
  • Usually defined as a supraclavicular position of the aortic arch
  • More common on the right side
  • 2:1 female:male predominance

Clinical Findings

  • Pulsatile neck mass
  • Stridor
  • Dyspnea
  • Dysphagia
  • Respiratory infections

Haughton Classification of Cervical Aortic Arches

Type A

Contralateral descending aorta and absence of one common carotid artery (separate external and internal carotid artery branches)

Type B

Contralateral descending aorta and presence of both common carotid arteries

Type C

Contralateral descending aorta and bi-carotid trunk

Type D

Ipsilateral descending aorta with normal sequence of brachiocephalic branching

Type E

Right aortic arch and right descending aorta


Imaging Findings

  • Apical mass
  • Absence of the normal aortic knob
  • Displacement of the trachea to the side opposite the arch
  • Right-side cervical arches usually descend on the left
  • Anomalous origins of the great vessels
  • Right-sided lesions
    • Right apical mass-like density
    • Absence of aortic knob on left
    • Aorta usually descends on left (80%)
    • Displace the trachea and esophagus forward
    • Branching of major vessels may be mirror-image
  • Left-sided lesions
    • Aortic knob appears at apex of left lung
    • Aorta usually descends on the left (70%)
    • Do not usually displace the trachea and esophagus forward

Differential Diagnosis

  • Buckling of the aorta from a pseudocoarctation may present a similar picture
  • Aneurysms of the great vessels


  • Right-sided lesions have been associated with the 22q11.2 deletion syndrome
  • Right-sided lesions more often associated with intracardiac abnormalities like VSD or conotruncal abnormalities
  • Left-side lesions more often associated with coarctation


  • Surgical treatment may be indicated for relief of tracheal and esophageal compression symptoms or for correction of associated vascular defects

Cervical Aortic Arch

Cervical Aortic Arch

Cervical Aortic Arch. Above: Axial, contrast-enhanced CT scan of the upper thorax shows the aortic arch (black arrow) extending above the level of the clavicles. Below: Frontal radiograph of the chest demonstrates the cervical arch at the apex of the left lung (white arrow) above the clavicles. There is no aortic arch in the normal location. The aorta descends on the left.
For this same photo without the arrows, click
here and here
For more information, click on the link if you see this icon

The cervical aortic arches. VM Haughton, KE Fellows and AE Rosenbaum. Radiology. 1975 Mar;114(3):675-81.


The Cervical Aortic Arch. R Moncada, M Shannon, R Miller, H White, J Friedman, And Wh Shuford. Ajr November 1975 Vol. 125no. 3 591-601

Human Malformations And Related Anomalies. RE Stevenson and JG Hall. Oxford University Press, 2006
