Neuroblastoma
Submitted by Peter Wang, MD


General Considerations

  • Malignant tumor of neural crest cells
  • Most common extracranial solid tumor in infancy
  • 7.8% childhood cancers
  • Most common posterior mediastinal mass in children

Clinical Findings

  • Age at presentation
    • < 1 year – 40%, good prognosis
    • 1-2 years – 35%
    • > 2 years – 25%
    • Older patients, metastatic disease - poor prognosis
  • Lymph nodes, liver, bone
  • 50% present with metastatic disease
  • Clinical signs
    • Mass effect on adjacent organs
    • Metastatic disease
      • >90% with urine homovanillic acid (HVA) and vanillylmandelic acid (VMA)
    • Locations
      • Abdominal Cavity (40% adrenal, 25% paraspinal ganglia)
      • Thoracic 15%
        • Posterior mediastinum
    • Pelvic 5%
    • Cervical 3%
    • Other 12%

Imaging Findings

  • Plain Film
    • Abdominal, chest, cervical mass
    • Calcification
    • Bone erosion (ribs, pedicles)
  • US
    • Heterogeneously echogenic
    • Calcification
    • Doppler for flow in encased vessels
  • CT
    • Lobulated, invasive
    • Encases vessels
    • Inhomogeneous (hemorrhage, necrosis, calcifications)
  • MRI
    • T1WI – hypointense
    • T2WI – bright, heterogeneous
    • Variable enhancement
    • Neural foramina, spinal canal extension
  • Scintigraphy
    • MIBG
    • Uptake by catecholamine producing tumors
    • Primary tumor and metastatic disease
    • Tc-99m MDP (Bone Scan)

Differential Diagnosis

  • Extramedullary hematopoiesis
  • Another neural tumor
  • Sequestration

Treatment

  • Surgery
  • Chemotherapy
  • Bone marrow transplantation

neuroblastoma

neuroblastoma

Mediastinal Neuroblastoma. On the left is a contrast enhanced coronal reformatted CT image of the chest that shows a large left-sided mass of inhomogeneous enhancement that is displacing the heart to the right. A vessel arises from the aorta to feed the mass (black arrow). On the right, a T1 weighted Gadolinium-enhanced MR image shows inhomogeneous enhancement of the mass which appears to have a component arising from the neural foramen (white arrow).
For more information, click on the link if you see this icon

For this same photo without the annotations, click here and here
