Diffuse Small Bowel Disease
Click on Blue Links for Imaging Examples




Sprue

 • 3 diseases: Celiac Disease of Children, Nontropical sprue and Tropical Sprue

• Celiac disease and Nontropical sprue improve on gluten-free diet

• Tropical sprue improves with antibiotics and folic acid

Imaging

• The hallmark features are: dilatation and dilution, especially in jejunum

            • Segmentation of the barium column occurs because it moves more slowly through areas of excessive fluid and separates from the rest of the column-not commonly seen with newer barium mixtures

            • Fragmentation is an exaggerated example of the irregular stippling of residual barium in the proximal bowel (which is normal)

Intussusception is not uncommon but is usually not obstructive; sprue has increased risk of ca and lymphoma

Moulage sign is caused by dilated loop with effaced folds looking like tube into which wax has been poured



 Scleroderma CORRECT ANSWER

 • Affects esophagus, small bowel and colon, sparing the stomach

• Atrophy of the muscular layers and replacement with fibrous tissue

• Associated with malabsorption

Imaging

• Whole small bowel is usually dilated with close approximation of the valvulae (hide-bound appearance) (stack-of-coins)

• Does not have increased secretions as does sprue

• May be associated with pneumatosis intestinalis



 Whipple’s Disease

 • Glycoprotein in the lamina propria of the small bowel is Sudan-negative, PAS-positive

• Clinically: arthralgia, abdominal pain, diarrhea and weight loss

• Treated with long term antibiotics-penicillin

• Very rare

Imaging

• The hallmarks of the disease are nodules and a markedly thickened bowel wall (picket-fence)

• Small bowel may or may not be dilated

• Affects jejunum mostly



 Amyloidosis

 • GI involvement is common

• Associated with malabsorption

Imaging

• Marked thickening of the valvulae (picket-fence)

• No dilatation or dilution

• Affects entire small bowel




 Hypoproteinemia

 • Hypoalbuminemia resulting from liver or kidney disease lower than 1.5 grams per cent

• Usually asymptomatic from intestinal edema itself

Imaging

• Changes are present throughout small bowel

• Loops are separated due to edema of walls

Folds are quite thick (picket-fence)



 Giardiasis

 • Giardia lamblia is a flagellated protozoan, a normal parasite of the small bowel

• Clinically: diarrhea and malabsorption

• Treated with metronidazole (Flagyl)

• Some patients have hypogammaglobulinemia and nodular lymphoid hyperplasia associated with giardiasis

Imaging

• Usually limited to duodenum and jejunum

Thickening of the folds

Marked spasm and irritability of the bowel

• Increased secretions is common



 Ischemic Bowel Disease

 • Thickening of the wall due to edema and hemorrhage

• Localized perforations can produce air in the bowel wall or in portal venous system

Imaging

• Spasm and irritability early is replaced by an atonic bowel later

• Lumen is narrowed

Folds are thickened, sometimes producing “thumb-printing”

• Healing may result in stricture formation



 Intramural Bleeding

 • Suggested if there is duodenal obstruction following trauma

• Localized lesions occur with trauma

• Diffuse lesions are seen with anticoagulants

Imaging

• Uniform, regular, thickening of the folds

• Separation of the loops

• Mass effect

• No spasm



 Radiation Enteritis

 • Changes are identical to ischemia since radiation changes are actually secondary to an arteritis with occlusion of small vessels

• Localized to area of radiation portal, especially pelvis in female 2° endometrial carcinoma treatment

• Previous adhesions from surgery may anchor small bowel in pelvic portal and predispose to XRT changes

• Mucosa is most sensitive to radiation

Imaging

• Localized thickening of the folds 2° edema and hemorrhage

• May result in strictures later in course



Lymphoma

• Most commonly involves terminal ileum

• Bowel wall becomes markedly thickened and submucosa infiltrated (picket-fence)

• “Thumb-printing“ may be seen

• Loops are widely separated and there may be mass effect

• Another form may have a large ulceration which is confined and produces so called “aneurysmal dilatation” of the bowel
